Programmable AC Power Sources

Programmable AC power sources from Preen, spanning compact bench units to megawatt-scale facility systems for grid simulation, compliance testing, and general R&D.

Programmable AC power sources reproduce the AC grid — voltage, frequency, phase, and waveform — under controlled, repeatable conditions, letting a product be tested against real-world grid variation, disturbances, and international voltage/frequency standards before it ever reaches a live installation. They're used across compliance testing (IEC 61000-4-11/13/34, GB/T harmonics standards), production-line burn-in and functional test, and general R&D bench work where a stable, adjustable AC supply is needed in place of the mains.

Below, Preen's range covers everything from compact bench units to megawatt-scale three-phase systems.

Preen
Available as a Containerized / IP54 Option
Every Preen AC power source below can be built into a customized outdoor container or upgraded to an IP54-rated enclosure, following the same approach as Preen's dedicated BPS shore power range — useful for ports, construction sites, remote installations, and other high humidity, heat, dust, or corrosion-exposed environments. Standard indoor chassis remain the default; contact Finch to configure a containerized or IP54 version for your application.
Preen AFV Series
AFV Series
High-Power Programmable AC Power Source, 10kVA to 1600kVA
Preen's core high-power AC source line, scaling from single-phase 10kVA bench units to three-phase 1600kVA facility-scale systems for home appliance, motor, and industrial R&D and compliance testing.
View Full Series →
Preen AFV+ Series
AFV+ Series
High-Power Programmable AC Source, 10kVA to 2000kVA
An upgraded high-power AC source extending to 2000kVA per unit with tighter THD (≤0.5%) and 3-phase-in/1-phase-out configurations for high-voltage motor and EV charger input testing.
View Full Series →
Preen AFV-P Series
AFV-P Series
High-Performance Programmable AC Power Supply with DC Output
A compact, high-performance source with THD under 0.3% and 300µs transient response, 600VA-5000VA, with a built-in DC output mode for combined AC/DC bench testing.
View Full Series →
Preen AFV-S Series
AFV-S Series
Compact Programmable AC Power Source, Entry-Level Alternative to AFV-P
Shares the AFV-P's 600VA-5000VA power range and touch screen without DC output mode — a simpler, cost-effective option for home appliance, LED lighting, and general manufacturing test.
View Full Series →
Preen AFC Series
AFC Series
AC Power Source / Frequency Converter
Economically priced source and frequency converter for general production and R&D, covering 500W single-phase bench units through to 640kVA three-phase systems, up to 92% efficiency.
View Full Series →
Inquire About Any Series →

How to Choose a Programmable AC Power Source

A programmable AC power source lets you test a product on any mains supply in the world, and on supplies that are deliberately imperfect, without changing your building's power. Six questions decide which one you need.

  1. Single or three phase: match the product and its markets. Many sources can be configured either way, which helps if you test both.
  2. VA rating and peak current: AC sources are rated in VA, not watts, so size from VA with margin. Products with rectifier front ends need a crest factor of 3 or more, or the source may limit or distort at switch-on.
  3. Frequency range: 50 and 60 Hz for global compliance, 400 Hz for aircraft and avionics, and wider ranges for motors and drives.
  4. Waveforms and disturbances: dips and interruptions (IEC 61000-4-11 and -4-34), harmonics (IEC 61000-4-13), DC and AC+DC output, and arbitrary waveforms.
  5. Source or grid simulator: if your product feeds power back, you need a regenerative grid simulator instead.
  6. Measurement, control and site power: built-in power and harmonic measurement, LAN/USB/RS-232/485/GPIB control, output isolation, and a three-phase site supply for larger units.

The full guide: how to choose a programmable AC power source.

Common AC Power Source Applications

ApplicationWhat you need
Global product compliance50 Hz and 60 Hz at each market's voltage, with variation either side
Aircraft and avionics400 Hz ground power to MIL-STD-704 and DO-160 Section 16/17
Dips and interruptions immunityIEC 61000-4-11 dips test systems
Harmonics immunityIEC 61000-4-13 harmonics testing
Continuous 60 Hz or 400 Hz supply to equipmentPreen AFC frequency converters
Inverters, EV chargers, regenerative drivesRegenerative grid simulators

Comparing Preen's compact ranges? See Preen AFV-S vs AFV-P.

Programmable AC Power Sources in Australia and New Zealand

Finch is the authorised Preen distributor for Australia and New Zealand and supplies programmable AC power sources from compact bench units to high-power three-phase systems, with local support from Melbourne.

Need a recommendation? Send us your product and test standard and we'll suggest the right source.

Frequently Asked Questions

What is a programmable AC power source?

A test instrument that outputs an adjustable AC supply, with programmable voltage, frequency and waveforms, so products can be tested on any mains supply and on deliberately disturbed supplies.

What is the difference between an AC power source and a frequency converter?

A frequency converter is built to supply a fixed different frequency, such as 60 Hz or 400 Hz, to equipment in continuous use. A programmable AC source is built for testing, with adjustable voltage, frequency and waveforms.

Can I use a variac or isolation transformer instead?

Only for simple voltage adjustment at mains frequency. They cannot change frequency, create dips or harmonics, or measure the output, which compliance testing needs.

When do I need a grid simulator instead of an AC source?

When the product feeds power back, such as a PV inverter, battery inverter, vehicle-to-grid EV charger or regenerative drive. A regenerative grid simulator absorbs that power and returns it to the grid.

Do you supply AC power sources in New Zealand?

Yes. Finch supplies and supports Preen programmable AC power sources across Australia and New Zealand.
