SMT-529T Test Probe Kit for IEC 60529 (IP Code)
LISUN SMT-529T probe kit for verifying the first IP code digit (IP1X–IP4X) to IEC 60529: 50mm sphere, jointed test finger, 2.5mm rod, 1.0mm wire and low-voltage contact indicator.
Enquire About This Product
Overview
The first digit of an IP rating states how well an enclosure keeps out solid objects and fingers. IEC 60529 verifies it with a set of probes of decreasing size, each pushed against every opening with a specified force. If the probe enters, it must not reach hazardous parts; for the higher digits, it must not enter at all.
The SMT-529T kit contains the four access probes needed for the IP1X to IP4X checks, plus a low-voltage test supply that lights an indicator if a probe touches a live part, so contact inside a closed enclosure is detected electrically rather than by eye.
Key Specifications
| LISUN model | Item | Used for |
|---|---|---|
| SMT-A50 | Sphere, 50mm diameter, 50N force | IP1X |
| SMT-02T10 | Jointed test finger, 10N force | IP2X |
| SMT-IP30T | Test rod, 2.5mm diameter × 100mm, 3N force | IP3X |
| SMT-IP40T | Test wire, 1.0mm diameter × 100mm, 1N force | IP4X |
| SMT-529CV | Low-voltage test supply / contact indicator | Detecting contact with live parts |
Features
- Complete probe set for IP1X to IP4X access verification
- Probes supplied with the specified test forces
- Low-voltage indicator supply for electrical contact detection
- Each probe also available individually
Applications
IP rating verification of electrical enclosures, luminaires, appliances, control panels and outdoor equipment; pre-compliance checks before third-party IP testing.
