MEWOI Portable Multi-Gas Detectors
MEWOI portable gas detectors measuring up to four, five or eight gases at once, including combustibles (LEL), CO, H2S, SO2, O2, CO2 and VOCs, with configurable ranges and sensors.
Enquire About This Product
Overview
Portable multi-gas detectors protect workers entering confined spaces and check for leaks and toxic atmospheres in plant rooms, tanks, pits and process areas. MEWOI's detectors are configured to order: you choose the gases and ranges, and the instrument is fitted with the matching sensor technology, whether electrochemical, catalytic combustion, infrared, thermal conductivity or PID photoionisation.
The MS104K is a fixed 4-in-1 detector for CO, H2S, O2 and combustible gas (LEL), the standard confined-space set. The MS400 takes any combination of one to four gases, and the MS500 five. The MS600 and PTM600 are portable composite analysers taking one to six gases, expandable to eight, for broader process and environmental monitoring. Temperature and humidity can be added as options.
Key Specifications
| Model | Gases |
|---|---|
| MEWOI-MS104K | 4-in-1: CO, H2S, O2, combustibles (EX) |
| MEWOI-MS400 | Any 1–4 gases |
| MEWOI-MS500 | 5-in-1 configurable |
| MEWOI-MS600 | 1–6 gases, expandable to 8 |
| MEWOI-PTM600 | Portable composite analyser, multiple gases |
| Typical specification (MS400) | Value |
|---|---|
| Gas types | Toxic gases, O2, CO2, combustibles, TVOC |
| Ranges | 0–1ppm up to 0–100,000ppm; 100% LEL; 20/50/100% Vol; custom ranges available |
| Resolution | Down to 0.001ppm (low ranges); 0.1% LEL; 0.001% Vol |
| Sensor principles | Electrochemical, catalytic combustion, infrared, thermal conductivity, PID |
| Accuracy / linearity | ≤±3% F.S. / ≤±2% |
| Response / recovery | T90 ≤30s / ≤30s |
| Operating environment | -40 to +70°C, up to 95% RH; built-in filters for dust and humidity |
| Options | Temperature and humidity; high-temperature sampling handle |
Features
- Configured to order with your choice of gases and ranges
- Up to 8 gases in one instrument (MS600)
- Electrochemical, catalytic, infrared, thermal conductivity and PID sensors
- Fast T90 response under 30 seconds
- Wide operating range, -40 to +70°C
Applications
Confined space entry; gas leak detection in plant and pipelines; petroleum, chemical and pharmaceutical sites; wastewater and utility pits; warehouse and environmental air checks.
