MEWOI Automatic Flash Point Testers — Open & Closed Cup
MEWOI automatic flash point testers for insulating oil and petroleum products: MEWOI502K open cup to 400°C and MEWOI501B closed cup to 300°C, with auto-ignition and pressure correction.
Enquire About This Product
Overview
Flash point is the lowest temperature at which an oil gives off enough vapour to ignite. For transformer oil it is a safety and contamination check: a flash point that has dropped below the oil's specification usually means lighter, more volatile hydrocarbons have formed (for example from arcing or overheating) or the oil has been mixed with another fluid.
MEWOI's automatic flash point testers run the whole test without operator intervention: the sample is heated to a PID-controlled standard curve, the igniter is applied automatically, an ion-detection ring senses the flash, and the instrument corrects the result for atmospheric pressure, raises an alarm, cools and prints. A touch-screen interface replaces keypad operation, and up to 256 time-stamped results are stored with RS232 output to a PC or printer.
Two versions are offered. The MEWOI502K is the open-cup instrument, measuring to 399.9°C, designed to GB/T 267, GB/T 3536 and ASTM D92 (Cleveland open cup). The MEWOI501B is MEWOI's closed-cup version, measuring to 299.9°C with tighter repeatability. Both share the same modular main unit, so a single controller can drive interchangeable open and closed test furnaces.
Key Specifications
| Specification | MEWOI502K (open cup) | MEWOI501B (closed cup) |
|---|---|---|
| Measuring range | -59.9 to 399.9°C | -59.9 to 299.9°C |
| Temperature control range | Room temperature to 400°C | Room temperature to 300°C |
| Repeatability | ≤150°C: 3°C; >150°C: 5°C | 0.025X (X = mean of two consecutive results) |
| Resolution | 0.1°C | 0.1°C |
| Precision | 0.5% | 0.5% |
| Temperature sensor | PT100 platinum RTD | PT100 platinum RTD |
| Flash sensor | Ion detection ring | Ion detection ring |
| Display | 320×240 graphic LCD, touch screen | 320×240 graphic LCD, touch screen |
| Data | 256 time-stamped records, thermal printer, RS232 | 256 time-stamped records, thermal printer, RS232 |
| Power | AC 220V, 50Hz, approx. 400W | AC 220V, 50Hz, approx. 400W |
| Dimensions / weight | 440 × 280 × 290mm / 14kg | 440 × 280 × 290mm / 14kg |
| Environment | 0–40°C, ≤85% RH | 0–40°C, ≤85% RH |
Features
- Fully automatic: heating, ignition, flash detection, alarm, cooling and printing
- Automatic barometric pressure measurement and correction
- Adaptive PID heating to the standard temperature curve
- Ion-ring flash detection and PT100 temperature measurement
- Modular design: one controller drives interchangeable open or closed test furnaces
- Over-temperature cut-off and alarm
- Touch-screen operation, 256-record memory, RS232 output
Applications
Transformer and insulating oil safety testing; detecting volatile contamination after faults or overheating; incoming inspection of new oil; flash point testing of lubricating oils and other petroleum products in utility and industrial laboratories.
