MT-UV — Mactron UV Laser Marker

The Mactron MT-UV Station UV Laser Marker uses a 355nm ultraviolet laser source for ultra-fine cold marking of heat-sensitive and delicate materials. The photo-chemical (cold) marking process causes negligible heat-affected zone — the material surface is modified without burning, deforming or damaging the substrate.

Power options: 3W, 5W, 8W, 10W and 15W. Available as station (MT-UV) or compact inline system (MT-SU). The station model features a closed vertical sliding door design with high-quality optical glass observation window. Optional automatic lifting, autofocusing and rotating functions.

Minimum marking character size: 0.2mm. Excellent for high-contrast markings on sensitive products.

Applications include: glass and transparent materials, silicone, white polyamides, ceramics, medical device marking (without surface damage), pharmaceutical blister packs, sensitive electronics components, flexible circuit boards.

No consumables. Low maintenance cost. Siemens electrical system. EU safety compliant.

Laser type: UV (355nm) | Power: 3W / 5W / 8W / 10W / 15W | Wavelength: 355nm | Minimum character: 0.2mm | Design: Station with vertical sliding door | Optional: autofocus, auto-lift, rotary

• 355nm cold UV marking — negligible heat-affected zone
• 3W, 5W, 8W, 10W, 15W power options
• Minimum character size: 0.2mm
• Closed station with optical glass observation window
• Optional autofocus, auto-lift and rotary
• For heat-sensitive and delicate materials
• Siemens electrical system; EU safety compliant

Medical device ultra-fine marking; Glass marking without breakage; Silicone and soft material marking; Pharmaceutical blister pack coding; Sensitive electronics component ID; Ceramic and fine ceramic marking; High-contrast marking on white or transparent materials; Flexible circuit board marking
