DWC Series Low Temperature Impact Test Device – LISUN

DWC-1 / DWC-2 / DWC-3

LISUN DWC series cold impact testers for cables (IEC 60811-506), plugs and sockets (IEC 60884-1) and conduit (IEC 61386-1), used at -15°C in a cold chamber.

Electrical Safety Test Equipment
Plug, Switch & Cable Test
Test Apparatus
IEC 60811-506 (IEC 60811-1-4); IEC 60884-1:2022 Clause 24.5 and 30.5; IEC 60670-1 Figure 21; IEC 61386-1:2020 Clause 10.3; IEC 60245-1; IEC 60227-1; GB/T 2951.14; GB/T 2099.1-2021; GB/T 20041.1-2015
Enquire About This Product
LISUN DWC Series Low Temperature Impact Test Device

Overview

Plastic and rubber insulation becomes brittle in the cold, so cable, accessory and conduit standards include an impact test at low temperature: the sample and the impact apparatus are cooled, then a weight is dropped on the sample and it is checked for cracks.

The DWC series are stainless steel impact devices for these tests, used inside a cold chamber such as the LISUN GDJW-500D at -15 ±1°C. Three versions cover different standards: the DWC-1 for cables to IEC 60811-506, IEC 60245-1 and IEC 60227-1, with hammers from 100g to 1500g; the DWC-2 for plugs, sockets and boxes to IEC 60884-1 Figures 30 and 42 and IEC 60670-1 Figure 21; and the DWC-3 for conduit to IEC 61386-1. Drop height is adjustable from 10 to 200mm, and other weights or standards can be made to order.

Key Specifications

SpecificationDWC-1DWC-2DWC-3
Impact weights100, 200, 300, 400, 500, 600, 750, 1000, 1250, 1500g1000g and 100g0.5, 1.0, 2.0, 6.8kg
StandardsIEC 60811-506, IEC 60245-1, IEC 60227-1IEC 60884-1 Clause 24.5 and 30.5; IEC 60670-1 Figure 21IEC 61386-1 Clause 10.3
Working temperature-15 ±1°C (in cold chamber)
Drop height10~200mm, adjustable
Sample length5D~150D
Material304 stainless steel

Features

Applications

Frequently asked questions

Does it need a cold chamber?

Yes. The device and samples are conditioned in a low temperature chamber, such as the LISUN GDJW-500D, before the impact.
