LISUN TTC-1 CTI and PTI tracking tester to IEC 60112, UL 746A and ASTM D3638: 100-600V, 0.1% NH4Cl drops every 30s, platinum electrodes; UL 2597 model 900V.
Enquire About This Product
The comparative tracking index (CTI) and proof tracking index (PTI) rate how well a solid insulating material resists forming conductive tracks when its surface is wet and contaminated. IEC 60112 measures them by dripping ammonium chloride solution between two platinum electrodes on the sample at a set voltage and checking whether it fails within 50 drops. The CTI is used to choose creepage distances in product standards.
The TTC-1 applies 100 to 600V AC (900V on the TTC-UL2597) with ±1% accuracy and drips 0.1% ammonium chloride solution at a 30 ±5s interval from 30 to 40mm. Leakage current is monitored from 0 to 100mA, and the test fails automatically if the current exceeds 0.5A for 2 seconds. A flame detector and automatic power-off protect the sample and operator. Standard electrodes are PT999 platinum (≥99.9%) to IEC 60112 Figure 1, at 1.0 ±0.05N each. The TTC-1 has a cabinet, the TTC-1S is the open version, and the TTC-UL2597 adds the UL 2597 surface tracking test for transport applications.
| Specification | TTC-1 | TTC-1S | TTC-UL2597 |
|---|---|---|---|
| Construction | With cabinet | Without cabinet | With cabinet |
| Test voltage | 100~600V AC | 100~900V AC | |
| Failure criterion | >0.5A for >2s, automatic stop | ||
| Solution | 0.1% ammonium chloride | ||
| Drops | Height 30~40mm; 44~55 drops/cm³; interval 30 ±5s | ||
| Leakage monitoring | 0~100mA ±2%, 60mA alarm | ||
| Sample | 100 × 100 × 2~10mm recommended, ≤15mm thick | ||
| Test time | 0~9999s | ||
| Electrodes | PT999 platinum, 1.0 ±0.05N each | ||
| Control | LCD touch screen with remote control | ||
| Weight | 180kg | 40kg | 180kg |
The TTC-1 tests CTI and PTI at up to 600V to IEC 60112. The TTC-2 tests high-voltage tracking at 1 to 6kV to IEC 60587.
Yes. PT999 platinum electrodes to IEC 60112 Figure 1 are supplied as standard.
