LISUN TEM-420-200 TEM Cell for EMC Testing

Overview

A TEM (transverse electromagnetic mode) cell is a closed, shielded section of transmission line. A flat inner conductor, or septum, runs between the walls of a rectangular outer conductor and tapers to a coaxial connector at each end. Fed with RF power, it produces a uniform, calculable electric and magnetic field between the septum and the floor, without the need for an anechoic chamber.

The LISUN TEM-420-200 is built to IEC 61000-4-20, ISO 11452-3 and IEEE 1309. It is used for radiated immunity tests on small electronic products and automotive components, for radiated emission measurements on small devices, and for calibrating E-field and H-field probes. It works from DC to 420MHz, or 550MHz as an option, and its calibration field strength is 200V/m.

What it is used for

The cell is compact and weighs about 10kg, so it suits R&D benches, pre-compliance work and laboratories building up their EMC capability. Samples up to 120mm cube are loaded through a 150 × 160mm door and sit on a low-permittivity support; their cables leave through a connector panel.

Key Specifications

ParameterValue
Frequency rangeDC–420MHz (DC–550MHz optional)
Rated calibration field strength200V/m
Impedance50 ±2Ω
VSWR<1.8 typical
Maximum input power1000W
Septum height200mm
Maximum sample size120 × 120 × 120mm
Door size150 × 160mm
Dimensions (L × W × H)420 × 850 × 430mm
RF connectorsN-type
WeightAbout 10kg
Sample supportRelative permittivity ≤1.4

Features

Applications

Frequently asked questions

What else do I need for immunity testing?

An RF signal generator, a power amplifier and a field probe or power meter. LISUN offers matching signal generators and amplifiers.

How large can the sample be?

Up to 120 × 120 × 120mm, which keeps it within the uniform field region under the septum.
