CD-320PRO Portable Colorimeter – LISUN

CD-320PRO

LISUN CD-320PRO pocket colorimeter: d/8 SCI spectral sensor, 400–700nm, ΔE≤0.1 repeatability, 26 illuminants, Bluetooth app with colour card libraries.

Material & Optical Analysis
Object Color & Glossiness Test
Handheld Instrument
ASTM E313; ASTM D1925; CIE colour spaces (CIELAB, LCh, Luv)
Enquire About This Product
LISUN CD-320PRO Portable Colorimeter

Overview

The CD-320PRO is a pen-sized colour meter for checking colour and colour difference on the spot. Unlike a simple tristimulus colorimeter, it uses a spectral sensor that returns reflectance data from 400nm to 700nm in 10nm steps, measured with d/8 diffuse illumination and the specular component included (SCI). That gives Lab, LCh, RGB, Hex and around 20 other parameters under 26 illuminants, including whiteness and yellowness indices, colour strength, colour fastness and opacity.

Results show on the instrument's 1.14-inch screen and sync over Bluetooth to the companion app on Android or iOS (Windows is also supported). The app sets colour difference tolerances and pass/fail limits, holds colour card libraries for print, paint and textile shades so you can find the closest match, and shares colour data through a cloud library with customers and suppliers. Black and white calibration is automatic, and the app reminds you when calibration is due.

Key Specifications

SpecificationCD-320PRO
Illumination / viewingd/8, SCI (specular component included)
Colour spaces and indicesReflectance, CIE-Lab, CIE-LCh, Hunter Lab, CIE-Luv, XYZ, Yxy, RGB; colour difference ΔE*ab, ΔE*cmc, ΔE*94, ΔE*00; whiteness (ASTM E313-00, ASTM E313-73, CIE/ISO, AATCC, Hunter, Taube Berger Stensby); yellowness (ASTM D1925, ASTM E313-00, ASTM E313-73); blackness (My, dM); staining and colour fastness; tint; CMYK density (A, T, E, M); metamerism index; Munsell; opacity; colour strength
Light sourceFull-wavelength balanced LED
Measuring aperture8mm
Wavelength range / interval400~700nm / 10nm
RepeatabilityΔE≤0.1 (white tile measured 30 times at 5-second intervals after calibration)
Measurement time1s
IlluminantsA, B, C, D50, D55, D65, D75, F1–F12, CWF, U30, U35, DLF, NBF, TL83, TL84
Observer2° and 10°
Display1.14-inch IPS full-colour screen
InterfaceUSB, Bluetooth
Battery4.2V / 760mAh rechargeable, 10,000 continuous tests
CalibrationAutomatic
SoftwareAndroid, iOS, Windows
Size / weightΦ31mm × 102mm; about 90g

Features

Applications

Frequently asked questions

Is the CD-320PRO a colorimeter or a spectrophotometer?

LISUN sells it as a colorimeter, but it uses a spectral sensor and reports reflectance from 400–700nm, which is what lets it calculate colour under 26 different illuminants.

What happened to the CD-200 and CD-300?

LISUN currently publishes the CD-320PRO only. Contact Finch if you need a specific earlier model.

How repeatable is it?

LISUN specifies ΔE≤0.1 when a white tile is measured 30 times at 5-second intervals after calibration.
