IK01-06P Pendulum Impact Test Device – LISUN

IK01-06P

LISUN IK01-06P pendulum impact tester to IEC 60068-2-75 Test Eha: 1000mm pendulum, 150g/200g strikers, IK01–IK06 (0.14–1J), digital angle and height.

Ingress Protection & Mechanical Test Equipment
Impact Test
Wall-Mounted Test Device
IEC 60068-2-75:2014 Clause 5 (Test Eha); IEC 60669-1:2020 Clause 20.1; IEC 60669-2-1:2021 Clause 18.1; VDE 0620-1:2022 Clause 9.4; GB/T 2423.55-2023; GB/T 2099.1-2021; GB/T 16915.1-2024
Enquire About This Product
LISUN IK01-06P Pendulum Impact Test Device

Overview

The LISUN IK01-06P is a pendulum hammer for the low-energy impact test of IEC 60068-2-75, Test Eha. It checks the mechanical strength of enclosures and parts such as switches, sockets, plugs, controls and small appliances against the knocks they may get in transport, installation and use, and covers impact ratings IK01 to IK06.

The striker hangs from a rigid 1000mm steel-tube pendulum. A digital display shows the pendulum angle and the equivalent drop height, which is calculated from the arm length and angle, so the operator can set any height from 1 to 1000mm accurately and repeat it from test to test.

How the test is done

The device is fixed to a solid vertical wall, and the mounting bracket adjusts forwards, backwards and sideways. The sample is mounted on the plywood board so that the impact point is level with the centre of the striker. With the pendulum hanging freely and just touching the sample, the display is zeroed. The pendulum is then raised to the height required by the standard, held on the release mechanism and released. After the specified number of impacts the sample is checked against the requirements of the product standard.

Key Specifications

Specifications

ParameterValue
Striker mass150 ±1g and 200 ±1g
Pendulum length1000 ±1mm
Pendulum tubeSteel, 9mm outside diameter, 0.5mm wall
Mounting bracket mass10 ±1kg
Bracket rotation±60°, ±90°
Drop height1–1000mm, adjustable
Display resolutionAngle 0.36°, height 0.1mm

Impact energies (IEC 60068-2-75 Table 2)

IK01IK02IK03IK04IK05IK06
0.14J0.2J0.35J0.5J0.7J1J

Features

Applications

Frequently asked questions

How is the drop height set?

The display calculates the striker height from the pendulum angle, so you raise the pendulum until the display shows the height given in the standard for the required IK level.

What about IK07 and above?

IK07 to IK10 need heavier strikers. LISUN's IK07-10 pendulum and vertical hammer testers cover those levels.
