LISUN XYL-VI Luminance Colorimeter

Overview

The XYL-VI measures luminance, chromaticity coordinates and colour temperature of light sources and illuminated surfaces from a distance. Unlike traditional colorimeters it uses digital X(λ), Y(λ) and Z(λ) sensors and a fully digital measuring system, with no analogue stage, so it avoids the zero drift that analogue instruments suffer from and has a wide dynamic range and good noise immunity.

It has a 1° measuring angle and works from 0.7m to infinity, reading luminance from 10 to 1,000,000 cd/m². Results show on a 128×64 LCD with data hold, and the RS232 interface and Windows software allow remote monitoring, data logging, printing and software calibration against other standard sources.

Key Specifications

SpecificationXYL-VI
Luminance range10~1,000,000 cd/m²; accuracy <5%
Luminance sensitivity / repeatability0.01 cd/m² / 0.01 cd/m²
V(λ) matchf1′ <5.5%
Measuring angle / distance1° / 0.7m to infinity
Chromaticity (x,y; u,v; u′,v′)Accuracy ±0.002, repeatability ±0.0005 (Illuminant A, above 10 cd/m²)
Colour temperature1,350~25,000K; sensitivity 1K; accuracy ±20K (Illuminant A, 100 cd/m²)
Temperature effect-0.1%
Refresh rate1/s (≥10 cd/m²); 1 per 3s (<10 cd/m²)
Display128×64 LCD with data hold
InterfaceRS232 with Windows 7/8/10/11 software
Power9V battery or 6V DC adapter
Size270×95×225mm (tripod optional)

Features

Applications

Frequently asked questions

How close can I measure?

From 0.7m to infinity, with a 1° measuring angle.

Can it be calibrated by the user?

Yes. Calibration is done in the software, and it can be corrected against other standard light sources for higher accuracy.
