LSRF-3 Flicker and Lamp Start Test System – LISUN

LSRF-3

LISUN LSRF-3 flicker tester: 100kHz Class A probe for flicker %, flicker index, SVM, Pst-LM and start-up time to ENERGY STAR, IEEE 1789, IEC TR 61547-1.

Lighting & Photometric Test Instruments
LED Flicker & Lamp Start Test
Bench-top Instrument
ENERGY STAR Lamps V2.1; IEEE Std 1789-2015; IEC TR 61547-1:2020; CIE TN 006:2016; IEC 60969:2013; SASO 2902-2018; (EU) 2019/2015; (EU) 2019/2020; BASIC/ASSIST; CA CEC
Enquire About This Product
LISUN LSRF-3 Flicker and Lamp Start Test System

Overview

The LSRF-3 measures how a light source behaves over time: flicker, start-up time, run-up (rise) time and stabilisation time. A high-speed CIE Class A photometric probe samples at up to 100kHz with a 16-bit converter, so it captures fast changes in light output that a normal meter would average out.

It can be fitted to LISUN's LPCE-2 and LPCE-3 integrating sphere systems or LSG goniophotometers, or to other brands' spheres and goniophotometers (goniophotometers need the CLAMP-LSRF fixture). Microsoft-certified software in English and Chinese generates the test reports. It suits LED lighting makers, self-ballasted lamp manufacturers and third-party test labs.

Three levels of testing

Key Specifications

ParameterLSRF-3
A/D conversion16-bit
PhotodetectorCIE Class A, V(λ) matched
Illuminance range0.1 lx~50,000 lx, 4 ranges
Sampling rateUp to 100kHz
Sampling time1s~200s
Strobe frequency error≤0.3%
Flicker index error≤0.010
Flicker percentage error≤5%
Flicker metricsFlicker percentage, flicker index, SVM, Pst-LM, Pst-LM(I) and others
Time measurementStart-up time, rise time (10%–90%), stabilisation time
SoftwareEnglish and Chinese; Windows 7/8/10/11; Microsoft-certified USB driver
ReportsStart-up, rise, stabilisation and flicker reports; PDF/Excel export

Features

Applications

Frequently asked questions

What do I need for ENERGY STAR start-up time testing?

The LSRF-3 with an integrating sphere and LISUN LSP-500VARC pure sine AC source, the standard configuration of the LPCE-2 system and LSG goniophotometers.

Can it measure Pst-LM(I)?

Yes, with the LSP-500VARC-Pst AC power source, which generates the voltage fluctuations IEC TR 61547-1:2020 requires.

Does it work with other manufacturers' integrating spheres?

Yes. LISUN states it can be integrated with other brands' spheres and goniophotometers.
