LS-B69A/B Induction Hob Test Vessels (IEC 60335-2-9) – LISUN

LS-B69A / LS-B69B

LISUN LS-B69A aluminium and LS-B69B steel induction hob test vessels to IEC 60335-2-9 Figs 103 and 104: five sizes, Ø110 to Ø300mm, boiling and oil tests.

Electrical Safety Test Equipment
Household Appliance Test
Test Vessel Set
IEC 60335-2-9:2019; IEC 60335-2-6:2020; GB 4706.14-2020; GB 4706.22-2020
Enquire About This Product
LISUN LS-B69A/B Induction Hob Test Vessels (IEC 60335-2-9)

Overview

Heating tests on induction hobs and cookers use standard vessels so that results are repeatable between labs. IEC 60335-2-9 specifies two kinds: a lidded aluminium vessel for water boiling tests (Figure 103) and a low-carbon steel vessel for cooking oil heating tests (Figure 104), in sizes matched to the cooking zones.

The LS-B69A aluminium vessels and LS-B69B steel vessels are made to those figures, with controlled wall and base thickness and flatness so that heat transfer is consistent. Fill quantities follow Table 101 of the standard.

Key Specifications

ItemLS-B69A (aluminium)LS-B69B (steel)
Material6061 aluminiumLow-carbon steel, ≤0.08% carbon
Sizes (diameter × height)Ø110×140, Ø145×140, Ø180×140, Ø220×120, Ø300×100mm
Base thickness8, 8, 9, 10, 10mm2, 2, 3, 3, 5mm (±0.5)
Side wall thickness2mm2 ±0.5mm
Base flatnessMax concavity 0.05mm, no protrusionConcavity ≤0.006d, no protrusion
FormCylindrical, flat base, with lidCylindrical, no handle or lid
TestWater boilingCooking oil heating
StandardIEC 60335-2-9 Figure 103IEC 60335-2-9 Figure 104

Features

Applications

Frequently asked questions

Which vessel is for which test?

The aluminium LS-B69A is for water boiling tests; the steel LS-B69B is for cooking oil heating tests.

How much liquid goes in?

The quantity is set by Table 101 of IEC 60335-2-9 for each vessel size.
