LPCE-2 Integrating Sphere Spectroradiometer System – LISUN

LPCE-2 (LMS-9000C) / LPCE-2 (LMS-9500C)

LISUN LPCE-2 LM-79 test system: molded integrating sphere, LMS-9000C or LMS-9500C spectroradiometer, power meter, sources and standard lamp in one rack.

Lighting & Photometric Test Instruments
LED Integrating Sphere Spectroradiometer System
Rack / Cabinet System
CIE 13.3:1995; CIE 177:2007; CIE 84:1989; ANSI C78.377-2024; ANSI/IES LM-79-24; ANSI/IES LM-80-21; (EU) 2019/2015; GB/T 5702-2019; GB/T 24824-2022
Enquire About This Product
LISUN LPCE-2 Integrating Sphere Spectroradiometer System

Overview

The LPCE-2 is LISUN's complete integrating sphere test system for measuring the light output, colour and electrical performance of lamps and luminaires. It combines a one-piece molded integrating sphere with built-in sample mount, a CCD spectroradiometer, digital power meter, AC and DC power sources, a NIST/NIM-traceable standard lamp and an auxiliary lamp for self-absorption correction, all in a 19-inch cabinet.

The molded sphere is more accurate than traditional multi-piece segmented spheres, and the system measures LEDs, energy-saving and fluorescent lamps and HID lamps to IES LM-79 and other international standards. It suits R&D prototyping, production quality control and third-party certification testing.

Two performance levels

What it measures

Key Specifications

ComponentLPCE-2 (LMS-9000C)LPCE-2 (LMS-9500C)
CCD spectroradiometerLMS-9000C industrial grade, VIS/UV-VIS/VIS-NIR; ±0.3nm; CCT ±0.3%LMS-9500C scientific grade, VIS/UV-VIS/VIS-NIR; ±0.2nm; CCT ±0.2%; Hamamatsu TE-cooled CCD
Digital power meterLS2050/LS2012: AC/DC voltage, current, power, PF/DF, harmonics to 50th order
Optical fibreCFO-1.5M, 1.5m low-loss fibre from sphere to spectroradiometer
AC power sourceLSP-500VARC/LSP-1KVAC pure sine output
DC power sourceDC series for standard lamps, auxiliary lamps and DC sources
Integrating sphereIS-1.5MA/IS-0.3M one-piece molded sphere with built-in sample stage, auxiliary lamp and cross-laser alignment
Standard lampSLS-50W/SLS-10W, traceable to NIM/NIST
Auxiliary lampRLS-100W/RLS-50W for self-absorption correction
CabinetCASE-19IN 19-inch rack with cable management
Optional LM-82 kitIS-1.5MT/IS-2.0MT constant-temperature sphere and TMP-8/TMP-16 multiplex temperature tester
Flux calculationSpectroscopic, photometric, and combined correction methods
SoftwareEnglish and Chinese; Windows 7/8/10/11; PDF/Excel reports

Features

Applications

Frequently asked questions

Which LPCE-2 version do I need?

The LMS-9000C version suits R&D, incoming inspection and general testing. The LMS-9500C version is for accredited labs and research institutions that need scientific-grade accuracy.

Can the LPCE-2 test at different ambient temperatures?

Yes, with the optional IS-1.5MT or IS-2.0MT constant-temperature sphere and TMP-8/TMP-16 temperature tester, for ANSI/IES LM-82 temperature characteristic testing.

What sphere size is supplied?

LISUN lists the IS-1.5MA and IS-0.3M spheres in the standard configuration. Larger spheres are available for bigger luminaires; ask Finch for a quote to your sample size.
