IK07-10VT Vertical Drop Hammer IK Impact Tester – LISUN

IK07-10VT / IK07-11VT

LISUN IK07-10VT vertical hammer tester to IEC 60068-2-75 Test Ehc and IEC 62262: 0.5, 1.7 and 5kg strikers, 200–600mm drop, magnetic release, IK07–IK10.

Environmental Test Equipment
IK Impact Test
Floor-Standing Test Instrument
IEC 60068-2-75:2014 Clause 7 (Test Ehc); IEC 62262:2021 Clause 7; ISO 2248; ANSI/UL 1993-2022 Clause 12.3; GB/T 2423.55-2023; GB/T 20138-2023; GB/T 4857.5-2019
Enquire About This Product
LISUN IK07-10VT Vertical Drop Hammer IK Impact Tester

Overview

The LISUN IK07-10VT tests the impact resistance of enclosures with a vertically falling hammer, the method of IEC 60068-2-75 Test Ehc and Clause 7 of IEC 62262 (IK code). It reproduces heavy objects falling on a product, or a product being struck in transport and service, and is used to prove IK07 to IK10 ratings. The IK07-11VT version extends this to IK11.

A rigid frame carries a guide tube that keeps the striker on a vertical path. An electromagnet holds the steel striker and releases it instantly, so it falls freely and repeatably. The drop height is set as soon as the lower end of the guide tube touches the sample surface, so no separate measurement is needed.

Typical uses

Key Specifications

Specifications

ParameterValue
ReleaseElectromagnetic, instant vertical release
Drop height200–600mm, adjustable (custom heights available)
StrikersSteel, 0.5kg, 1.7kg and 5kg (one of each)
Base plate800 × 800 × 10mm

IK energies and strikers (IEC 60068-2-75)

IK codeEnergyStriker massDrop height
IK072J0.5kg400mm
IK085J1.7kg300mm
IK0910J5kg200mm
IK1020J5kg400mm

IK11 (50J) is available with the IK07-11VT.

Features

Applications

Frequently asked questions

Pendulum or vertical hammer?

IEC 62262 allows either. A vertical hammer is easier for large or horizontal surfaces such as cabinet tops and luminaire lenses; a pendulum suits vertical surfaces and wall-mounted products.

Is IK11 available?

Yes, with the IK07-11VT.
