IK01-07 Spring Impact Hammer (IK01–IK07) – LISUN

IK01 to IK07 single hammers / IK01-06 adjustable hammer

LISUN spring impact hammers to IEC 60068-2-75 Test Ehb: single-energy hammers IK01–IK07 (0.14–2J) or one adjustable IK01-06 hammer, for enclosure tests.

Environmental Test Equipment
IK Impact Test
Hand-held Test Instrument
IEC 60068-2-75:2014 Clause 6 (Test Ehb); IEC 62262; IEC 60598-1 Clause 10; IEC 60335-1 Clause 21; IEC 61010-1 Clause 7; IEC 60065 Clause 9; IEC 60320-1; IEC 60400; IEC 60601-1 Clause 16; IEC 61058-1; IEC 60730-1; UL 1244; GB/T 2423.55-2023
Enquire About This Product
LISUN IK01-07 Spring Impact Hammer (IK01–IK07)

Overview

The spring hammer is the most widely used impact tool in product safety testing. Held against the product and cocked, a calibrated spring drives the striker into the surface with a set energy, checking that enclosures, operating levers, handles, knobs, indicator lamps, signal lights and lamp covers survive the knocks and misuse they may meet in service.

LISUN spring hammers are built to IEC 60068-2-75 Test Ehb with a one-piece body and a precision spring mechanism, so each blow delivers the specified energy repeatably. They are used across luminaires, household appliances, laboratory and measuring equipment, medical equipment, appliance couplers, switches and controls.

Two types

All LISUN spring hammers can be calibrated with the LISUN IK01-07-CAL calibration device to IEC 60068-2-75 Annex B.

Key Specifications

IK codeEnergy
IK010.14J
IK020.2J
IK030.35J
IK040.5J
IK050.7J
IK061J
IK072J (single hammer only)

Features

Applications

Frequently asked questions

Single or adjustable hammer?

The adjustable IK01-06 covers six levels in one tool and suits laboratories testing many product types. Single hammers are simplest where only one or two energies are used, and IK07 (2J) is only available as a single hammer.

How do I keep the hammer accurate?

Have it calibrated regularly; the LISUN IK01-07-CAL lets you check it in-house.
