LISUN LS-IEC62115C19 Toy Radiation Hazard Test System

Overview

Clause 19 of IEC 62115 controls the photobiological safety of light sources in electric toys, to protect children's eyes and skin from photochemical and thermal damage. The LS-IEC62115C19 is a complete test system for that clause. It measures radiant intensity, irradiance, beam angle, peak and dominant wavelength and bandwidth of toy light sources, and evaluates blue light hazard and UV levels under conditions that simulate how children use the toy.

Three array spectral measurement heads cover 200nm to 1700nm, a flicker module samples at up to 100kS/s, and a programmable two-axis rotating stage and automatic probe switching position the toy. UV and visible/NIR irradiance standard sources with NIM certificates calibrate the system, and AC and DC supplies, a power meter and a 19-inch cabinet complete it.

Key Specifications

PartItemNotes
Radiation and similar hazards test system
1.1Photobiological UV hazard test system200~400nm, 1nm interval, 0.2nm accuracy, 100,000:1 dynamic range
1.2Photobiological visible/NIR hazard test system400~1000nm, 1nm interval, 0.2nm accuracy
1.3Photobiological NIR hazard test system1000~1700nm, 1nm interval, 0.4nm accuracy
1.4Flicker test module300~1100nm, up to 100kS/s
1.5 / 1.6Analysis software; industrial computer and monitor–
Optical test bench
2.1Programmable 2D rotating stageSamples to 150mm and 5kg; -90°~+90° horizontal and vertical
2.2System platformAutomatic probe switching; distance 10~200mm
Standard sources
3.1UV irradiance standard source200~400nm, NIM certificate
3.2Visible and NIR irradiance standard source380~1700nm, NIM certificate
Power and cabinet
4.1–4.4LSP-500VARC AC source, DC3005 DC supply, LS2012 power meter, CASE-19IN cabinet–

Features

Applications

Frequently asked questions

What does IEC 62115 Clause 19 cover?

Radiation and similar hazards from light sources in electric toys, including blue light and UV, to protect children's eyes and skin.

Can it measure flicker in toy lights?

Yes. The flicker module covers 300–1100nm at up to 100kS/s.
