DT Series Automatic Drop Test Machine – LISUN

DT-60KG-D / DT-80KG-D / DT-80KG-S / DT-100KG-S

LISUN DT automatic drop testers for packages and products to ISO 2248, ASTM D5276 and ISTA 3A: face, edge and corner drops, 300–1500mm, up to 100kg.

Environmental Test Equipment
Drop Test
Floor-Standing Drop Test Machine
ISO 2248:1985; ASTM D5276-2019; ISTA 3A-2021; JIS Z 0202-1987; GB/T 4857.5-1992; GB/T 2423.5-2019; GB 4943.1-2022
Enquire About This Product
LISUN DT Series Automatic Drop Test Machine

Overview

The LISUN DT series drops packaged goods and products from a set height onto a rigid steel impact plate, to simulate the drops they meet in handling, transport, loading and unloading. It shows whether packaging protects the product and whether the product itself survives, and is used for factory inspection and certification testing of electrical and electronic products and packaged goods.

An electric lift raises the sample to the set height and locks it in place. When the test starts, the release mechanism opens quickly and cleanly so the sample falls freely, without swinging, dragging or touching the arms on the way down. Drop height and arm spacing are adjustable to suit the sample, and the sample can be dropped on a face, an edge or a corner. A digital display shows the height, avoiding reading errors.

Double-arm or single-arm

The DT-60KG-D and DT-80KG-D are double-arm machines for drops from 400 to 1500mm. The DT-80KG-S and DT-100KG-S are single-arm machines for drops from 300 to 1500mm, with a larger impact plate.

Key Specifications

ModelDT-60KG-DDT-80KG-DDT-80KG-SDT-100KG-S
TypeDouble armDouble armSingle armSingle arm
Drop height400–1500mm ±10mm300–1500mm ±10mm
Impact plate1400 × 1200 × 10mm1700 × 1200 × 10mm
Maximum sample weight60kg80kg80kg100kg
Maximum sample size800 × 800 × 1000mm1000 × 1000 × 800mm1000 × 1000 × 800mm1000 × 1000 × 800mm
Machine size1400 × 1200 × 2200mm1700 × 1200 × 2315mm
Machine weight420kg495kg495kg495kg
Drop orientationFace, edge and corner
PowerThree phase 380V, 50Hz (60Hz optional)

Features

Applications

Frequently asked questions

Which height do I need?

Drop height usually depends on package weight, as in ISTA 3A. All DT models reach 1500mm.

Double arm or single arm?

Double-arm machines suit most cartons up to 60 or 80kg; the single-arm models start lower, at 300mm, and the DT-100KG-S takes up to 100kg.
