LISUN DC3005 Series High Precision CC/CV DC Power Supply

Overview

Photometric standard lamps and LEDs must be driven at a precisely known current or voltage, because small supply changes alter their light output. LISUN's DC series are adjustable constant current (CC) and constant voltage (CV) power supplies with resolution down to 0.0001V and 0.0001A and high stability.

Six models cover 30V/5A to 300V/2.5A, from 150VA to 750VA. They are used to power standard lamps for calibrating integrating spheres and goniophotometers, and to drive LEDs and other DC samples in photometric and electrical testing.

Key Specifications

SpecificationDC3005DC3010DC6005DC6010DC12005DC30005
Max output power150VA300VA300VA600VA600VA750VA
Max output30V/5A30V/10A60V/5A60V/10A120V/5A300V/2.5A or 150V/5A
Voltage resolution0.0001V (0~10V); 0.001V (10~100V); 0.01V (>100V)
Voltage accuracy±(0.02% rdg + 0.01% rng + 1 digit)
Current resolution0.0001A
Current accuracy±(0.02% rdg + 0.01% rng + 1 digit) below 5A; ±(0.03% rdg + 0.02% rng + 1 digit) at 5A and above

Features

Applications

Frequently asked questions

Why use this for standard lamps?

A standard lamp's calibrated output only holds at its specified current. The DC series sets and holds current to 0.0001A with 0.02% accuracy.

Which model do I need?

Choose by the voltage and current your lamp or sample needs: from the 30V/5A DC3005 up to the 300V DC30005 for higher-voltage loads such as LED strings.
