CSS61000-11 Voltage Dips and Interruptions Generator – LISUN

CSS61000-11 / CSS61000-11T / CSS61000-11T-32A / CSS61000-11T-100A

LISUN CSS61000-11 voltage dip, interruption and variation generator to IEC 61000-4-11 (single phase) and IEC 61000-4-34 (three phase, to 100A).

EMC & EMI Test Equipment
Voltage Dips & Interruptions Generator
Bench-top Instrument
IEC 61000-4-11:2020; IEC 61000-4-34:2025; GB/T 17626.11-2025; GB/T 17626.34-2012
Enquire About This Product
LISUN CSS61000-11 Voltage Dips and Interruptions Generator

Overview

The CSS61000-11 series simulates the mains supply problems equipment meets in real life: voltage dips, short interruptions and voltage variations. It tests whether a product keeps working, restarts properly or keeps its data when the supply sags or drops out.

The single-phase CSS61000-11 follows IEC 61000-4-11 for equipment up to 16A; the three-phase CSS61000-11T models follow IEC 61000-4-34 for equipment over 16A per phase, up to 100A. Dip level runs from 0 to 110% with the IEC levels (100%, 80%, 70%, 40%, 0%) built in, dip phase is set in 1° steps, and duration, interval and count are programmable. A large Android touch screen in English and Chinese recalls standard tests with one touch.

Typical uses

Key Specifications

SpecificationCSS61000-11CSS61000-11TCSS61000-11T-32ACSS61000-11T-100A
WaveformAC sine wave
Dip range0~110%
Built-in IEC levels100%, 80%, 70%, 40%, 0%
Dip phase0°~360° in 1° steps
Dip duration0.5~9,999.5 cycles
Dip interval1~9,999ms
Dip count0~9,999
Operating modeAutomatic dipOne to three phases dipped at once
TriggerManual, automatic, 50ms
EUT supplySingle phase AC 220V ±10%, 16A maxThree phase AC 380V ±10%, 20A/phaseThree phase AC 380V ±10%, 32A/phaseThree phase AC 380V ±10%, 100A/phase
Working powerAC 220V (110V optional) ±10%, 50/60Hz

Features

Applications

Frequently asked questions

What is the difference between IEC 61000-4-11 and IEC 61000-4-34?

IEC 61000-4-11 covers equipment drawing up to 16A per phase; IEC 61000-4-34 covers equipment over 16A per phase. The CSS61000-11 covers the first and the CSS61000-11T models the second.

Can it dip one phase of a three-phase supply?

Yes. The three-phase models can dip one, two or three phases at the same time.
