CDNE-M316 / CDNE-M216

LISUN CDNE-M316 and CDNE-M216 coupling/decoupling networks for the CISPR 15 radiated disturbance method from 30MHz to 300MHz, used with an EMI receiver.

EMC & EMI Test Equipment
EMI Test System
Accessory
CISPR 15:2018; EN 55015; GB 17743
Enquire About This Product
LISUN CDNE-M316 Coupling Decoupling Network (CISPR 15)

Overview

CISPR 15, the emission standard for lighting equipment, lets you assess radiated disturbance from 30MHz to 300MHz with a coupling/decoupling network for emission (CDNE) instead of an antenna in a chamber. The lamp or luminaire is powered through the CDNE, which measures the common-mode interference on its leads; at these frequencies that interference is what the leads radiate.

The LISUN CDNE-M316 and CDNE-M216 work with an EMI receiver to make that measurement, giving a result equivalent to the radiated test without the cost of an anechoic chamber. A CDNE is included with LISUN's EMI-9KC receiver system.

Key Specifications

ItemSpecification
ModelsCDNE-M316, CDNE-M216
Frequency range30MHz~300MHz
MeasurementRadiated electromagnetic disturbance (equivalent method), with EMI receiver
StandardsCISPR 15:2018 / EN 55015; GB 17743

Features

Applications

Frequently asked questions

Can I use a CDNE instead of a chamber?

For lighting equipment, CISPR 15 accepts the CDNE method for 30–300MHz. Check your product standard; other product families may require an antenna measurement.

Which receiver do I need?

Any EMI receiver covering 30–300MHz. LISUN's EMI-9KC system includes a CDNE.
