Overview
The RF Technology 3m Full Anechoic Chamber (FAR) is a fully absorber-lined shielded room with electromagnetic absorbers covering all six surfaces — four walls, ceiling, and floor — providing a true free-space electromagnetic environment. Unlike a semi-anechoic chamber, the FAR eliminates ground-plane reflections, making it ideal for antenna characterisation, radar cross-section (RCS) measurements, and testing at frequencies below 30MHz where ground-plane effects are significant.
The chamber is used for precision antenna pattern measurements, gain and directivity characterisation, antenna efficiency testing, and near-field to far-field transformations. It meets the requirements for full anechoic performance across the design frequency range and is constructed with pan-type galvanised steel shielding and RF Technology's hybrid or microwave absorber systems.
Supplied and installed in Australia by Finch Electronic Solutions as a complete turnkey project.
Key Specifications
Measurement distance: 3m | Six-surface absorber lining (walls, ceiling, and floor) | Frequency range: custom to application | Shielding: pan-type galvanised steel | Absorber type: hybrid or microwave | Custom chamber dimensions on enquiry
Features
- Full six-surface absorber lining — true free-space electromagnetic environment
- Eliminates ground-plane reflections; suitable for sub-30MHz and antenna measurement
- Pan-type galvanised steel shielding construction
- Hybrid or microwave absorber options
- Suitable for antenna pattern, gain, RCS, and near-field measurements
- Custom sizing available; shielded door options include swing and sliding configurations
- Turnkey supply and installation by Finch Electronic Solutions
Applications
Antenna radiation pattern measurement; Antenna gain and directivity characterisation; Radar Cross Section (RCS) measurement; Near-field to far-field transformation; Sub-30MHz radiated emission testing; Antenna efficiency and total radiated power (TRP) testing; Military and defence antenna qualification; Satellite and aerospace antenna testing
