LSG-6000 — LISUN Goniophotometer
LISUN LSG-6000 LM-79 Mirror Type C Moving Detector Goniophotometer — automatic 3D light intensity distribution system for all luminaire types. IES, CIE, EN13032-1 compliant.
Enquire About This Product
Overview
The LSG-6000 is a Moving Detector Goniophotometer (Mirror Type C) designed to IES LM-79-24, IES LM-79-19 clause 8.1, EN13032-1 clause 6.1.1.3 type 4, CIE, IEC and GB standards. It is an automatic light distribution intensity 3D curve testing system. The darkroom can be designed to suit the customer's existing room size.
The LSG-6000 measures all types of lighting sources including CFL, HID and LED luminaires — indoor, outdoor, plant/horticultural, roadway, street lamps, flood lights and other luminaires.
Key hardware includes Japan MITSUBISHI servo motors, a German angle decode system and a Constant Temperature Class L Photo Detector for high measurement accuracy.
The system outputs: Luminous Intensity Data, Luminous Intensity Distribution, Zonal Luminous Flux, Luminaries Efficiency, Luminance Distribution (option), Coefficient of Utilization, Luminance Limitation Curves Glare, Maximum Ratio of Distance to Height, Equal Illuminance Diagrams, Curves of Luminaires VS Lighting Area, Isocandela Diagrams, Efficient Luminescence Angle, EEI, UGR, CCT, CRI, Color Temperature Distribution, Spectrum, (x,y)/(u,v), PAR, PPF, PPFD 3D distribution test and more.
Results can be exported as CIE, IES and LDT format files compatible with DiaLux and other lighting design software. Can be upgraded to LSG-6000CCD Goniospectroradiometer by adding a USB CCD Spectroradiometer for spatial CCT and spectral distribution testing including plant lighting PAR, PPF and PPFD spatial distribution.
Key Specifications
Angle accuracy: 0.05°; Angle resolution: 0.001° | Export formats: CIE, IES, LDT | LSG-6000/LSG-6000CCD: Testing lamp Ø1600×600mm, 50kg, measuring power 600V/10A AC/DC, min darkroom height 4100mm | LSG-6000L/LSG-6000LCCD: Ø2000×900mm, 80kg, 5200mm darkroom | LSG-6000B/LSG-6000BCCD: Ø1800×800mm, 60kg, 4700mm darkroom | LSG-6000S/LSG-6000SCCD: Ø1200×500mm, 40kg, 3000mm darkroom
Features
- Mirror Type C Moving Detector design
- Japan MITSUBISHI servo motors; German angle decode system
- Constant Temperature Class L Photo Detector
- Automatic 3D light distribution intensity curve testing
- Darkroom designed to customer's existing room size
- Exports CIE, IES, LDT files (DiaLux compatible)
- Optional CCD Spectroradiometer upgrade (LSG-6000CCD) for spatial CCT/spectrum
- Plant lighting PAR, PPF, PPFD 3D distribution test support
- Reports: Main, UGR, ISO PPFD, 3D Spectrum Distribution, Pre-Burn & Stabilization, Roadway CU
Applications
Indoor and outdoor LED luminaire photometric testing; Road and street lighting; Flood lighting; Plant / horticultural lighting; CFL and HID lamp testing; Lighting design data generation (DiaLux); Energy efficiency classification (EEI)
